Uni-3 Bench Scale

$2,979.50Price
With premium-class presets, fast print speed and extensive labeling functions, the Ishida Uni-3 Series offers more flexibility and features—all for less cost than comparable price computing scales with printers.
With three models and two display types, operators can easily find an Ishida Uni-3 to fit specific application needs. Ethernet or optional wireless communication enables any Uni-3 to be added to an existing network—ensuring operators have consistent control of all scales in your store.
Product management software ensures easy file maintenance as well as PLU and tare weight consistency throughout your operation. The power of the Uni-3 is at your fingertips with configurable preset buttons to represent PLUs, container tare values, label formats, images and logos.
The Uni-3 L1 model features a vibrant blue alphanumeric display with a sharp white 16-segment capability. The Uni-3 L2 model features a clear LCD display with one line alphanumeric and one line numeric. Each model offers a matching customer display.
Quantity

  • Specifications

    Capacity (Dual Range):
    0 to 15 × 0.005 lb/15 to 30 × 0.01 lb

    Capacity (Single Range):
    0 to 60 × 0.02 lb option

    Weighing Resolution:
    3,000 display divisions maximum

    Display Types:
    L1: LCD, blue alphanumeric (23 digits 16 seg)
    L2: LCD, backlight, alphanumeric (192 × 16 DM + 23 digits 7 seg)

    Display Items:
    Tare: Four-digits
    Weight: Five-digits
    Total price: Six-digits

    Preset Keys:
    84 one-touch preset keys 168 presets (assign two items/key)

    Memory Capacity:
    2 MB

    Communications:
    TCP/IP 10/100 Base T Ethernet

    Platter:
    14.5 × 10.5 in

    Printing Speed:
    3.9 in (100 mm) per second

    Printing:
    Direct thermal 2.2 in (56 mm)

    Label Size:
    Width: 1.5 to 2.5 in (38 to 64 mm)
    Length: 1.2 to 6.9 in (30 to 175 mm)

    Label Roll:
    Inside diameter: 1.6 in (40 mm)
    Outside diameter: 3.9 in (100 mm)

    Label Backing Paper:
    Width: Up to 2.6 in (66 mm)

    Power Supply:
    AC100 to 240 V, 50/60 Hz

    Power Consumption:
    Stand-by: 50 W
    In operation: 100 W

    Classification:
    NTEP CC 07-005
    UL Listed

    Warranty:
    One-year limited
